HDRM 150
Lightweight, powerful and efficient for light commercial vehicles.
The HDRM™150 Series are rare earth magnet-free motors developed in response to customer demand for a lightweight, freewheeling motor to drive light commercial vehicles and trailer-driven systems. A uniquely recyclable option is in development using patented aluminium windings.
Product Range
HDRM™150TC Air-Cooled
Peak Power32 kW
Continuous Power15 kW
Peak Torque60 Nm
Continuous Torque32 Nm
Maximum Speed8,400 rpm
Weight29.5 Kg
CoolingAir
HDRM™150TC Water-Cooled
Peak Power41 kW
Continuous Power30 kW
Peak Torque85 Nm
Continuous Torque60 Nm
Maximum Speed8,400 rpm
Weight20 Kg
CoolingWater / Glycol
Benefits
Sustainable
Uniquely recyclable rare earth magnet-free design
Manufacturable
A simplified design, easy to manufacture and integrate
Scalable
Smaller, lightweight motor for light commercial use
About HDRM™150TC
The HDRM™150 Series are rare earth magnet-free motors developed in response to customer demand for a lightweight, freewheeling motor to drive light commercial vehicles and trailer-driven systems. A uniquely recyclable option is in development using patented aluminium windings.
Features
Sustainable, magnet-free motor with recyclable option.
Ingress Protection level IP6K9K1.
No risk of demagnetization, allowing motors to run faster and hotter.
No back-EMF or short circuit current to ensure safe failure modes.
No cogging at high speeds for high drive cycle efficiencies.
Compressed windings to reduce mass and enhance continuous performance.
Aluminium compressed windings in development to produce uniquely recyclable motor.
Air-cooled for simplicity.
Available with or without fan and cowling.
Applications
One of the biggest opportunities in the field of electrification is the development and rollout of sustainable motor technology to the commercial sector.
HDSRM150 is a direct response to a call for a version of AEM’s HDSRM300 motor solution for light commercial vehicle usage and trailer driven systems.
A Trusted Supplier
AEM motors are powering a range of vehicles across the world and have now amassed over 4 million kilometers.
